产品详情
ABB三相监视器 ABB三相监视器继电器 ABB三相监视器 继电器
ABB视器继电器 ABB视器继电器 ABB继电器 ! ABB电流监视！ 监视！ 监视！
ABB视器继电器 ABB视器继电器 ABB继电器 ! ABB电流监视！ 监视！ 监视！
ABB三相监视器CT-MFE 24-240V AC/DC 0.05s-100h 1c/o 多功能 电流监视器CM-SRS
CT-ERE 24V AC/DC 220-240 VAC 0.1-10s 1c/o 3-300s 1c/o 0.3-30min 1c/o 0.3s-30s 1c/o 通电延时 三相监视器
CT-ERE 24V AC/DC 220-240 VAC 0.1-10s 1c/o 3-300s 1c/o 0.3-30min 1c/o 0.3s-30s 1c/o 通电延时 三相监视器
CM-PBE缺相监视，带中性线220-240V AC 1no
缺相监视，不带中性线3 x 380-440V AC 10012584 610.00
CM-PVE 电压监视，带中性线185-265V AC 1no
电压监视，不带中性线3 x 320-460V AC *10012582 659.00
CM-PFE相序监视
3 x 208-440V AC 1c/o - *10012574 501.00
CM-PFS.S 3 x 200-500V AC 2c/o - *10001342 681.00
CM-PSS.31S电压监视， 固定阈值，不带中性线，相序监视功能可选
3 x 380V AC, 50/60Hz 1x2c/o 0, 0.1-30s
CT-AHE代理商 CT-AHE价格 CT-AHE资料 CT-AHE现货
ABB三相监视器 CM-PSS.41S 3 x 400V AC, 50/60Hz
CM-PVS.31S 3 x 160-300V AC, 50/60Hz 1x2c/o 0, 0.1-30s
CM-PVS.41S 3 x 300-500V AC, 50/60Hz *10102318 1,772.00
三相监视器 CM-PAS.31S 不平衡监视，阈值可调，不带中性线 3 x 160-300V AC, 50/60Hz 1x2c/o 0, 0.1-30s
CM-PAS.41S 3 x 300-500V AC, 50/60Hz 10102322 1,751.00
CM-MPS.11S 多功能监视，带中性线，可用于单相，相序监视功能可选3 x 90-170V AC, 50/60Hz 1x2c/o 0, 0.1-30s
CM-MPS.21S 3 x 180-280V AC, 50/60Hz
CM-MPS.31S 三相多功能监视，不带中性线，
相序监视功能可选3 x 160-300V AC, 50/60Hz 1x2c/o 0, 0.1-30s
视器继电器 CM-MPS.41S 3 x 300-500V AC, 50/60Hz
CT-VWE 24V AC/DC 220-240V AC 0.1-10s 1c/o 3-300s 1c/o 0.3-30s1c/o通电脉冲延时
CM-MPS.23S 多功能监视，带中性线,可用于单相，相序自动校正功能可选
3 x 180-280V AC, 50/60/400Hz 1x2c/o，2x1c/o 0, 0.1-30s
三相监视器CM-MPS.43S 多功能监视，不带中性线，
相序自动校正功能可选3 x 300-500V AC, 50/60/400Hz
CM-MPN.52S多功能监视，不带中性线，相序自动校正功能可选3 x 350-580V AC, 50/60Hz 1x2c/o，2x1c/o 0, 0.1-30s
三相监视器CM-MPN.62S 3 x 450-720V AC, 50/60Hz
视器继电器 CM-MPN.72S 3 x 530-820V AC, 50/60Hz
CT-VWE
General Inbation
- Extended Product Type:CT-VWE
- Product ID:1SVR550130R1100
- EAN:4013614346378
- Catalog Description:CT-VWE Time relay, impulse-ON 1c/o, 0.1-10s, 110-130VAC
- Long Description:The CT-VWE is a single-function electronic time relay from the CT-E timer range. It provides an impulse-ON (interval) function with a time range from 0.1 s to 10 s. This time relay operates with a rated control supply voltage of 110 - 130 V AC and has a 1 c/o (SPDT) output rated at 250 V / 4 A.
Categories
- Products » Low Voltage Products and Systems » Control Products » Electronic Relays and Controls » Time Relays
Ordering
- Minimum Order Quantity:1 piece
- Customs Tariff Number:85364900
- EAN:4013614346378
Container Inbation
- Package Level 1 Width:84.2 mm
- Package Level 1 Length:24.6 mm
- Package Level 1 Height:83.1 mm
- Package Level 1 Gross Weight:0.076 kg
- Package Level 1 Units:1 piece
Dimensions
- Product Net Height:78 mm
- Product Net Depth:78.5 mm
- Product Net Weight:0.064 kg
- Product Net Width:22.5 mm
Technical
- Time Range:0.1-10 s
- Rated Control Supply Voltage (Us):110 ... 130 V AC
- Output:1 c/o (SPDT) contact
- Terminal Type:Screw Terminals
- Mounting Position:Any
-
Mounting on DIN Rail:TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715 -
Standards:IEC 61812-1
EN 61812-1 + A11
DIN VDE 0435 part 2021 - Timer Relay Type:Impulse - ON
Environmental
- RoHS Status:Following EU Directive 2002/95/EC August 18, 2005 and amendment
Certificates and Declarations (document Number)
- Instructions and Manuals:1SVC550000M9000
- CB Certificate:CB_DK-8575
- CCC Certificate:CCC_2010010303393101
- cUL Certificate:cUL508_E140448
- Data Sheet, Technical Inbation:2CDC111148D0201
- Declaration of Conbity - CE:1SVD981002-0000
- EAC Certificate:EAC_RU_C-DE.ME77.B.02016
- GL Certificate:GL_94633-94HH
- GOST Certificate:GOST_8572616
- RMRS Certificate:RMRS_12.04010.250
- RoHS Inbation:1SAA981001-4404
- UL Certificate:UL508_E140448
Classifications
- ETIM 4:EC001439 - Timer relay
- ETIM 5:EC001439 - Timer relay
- ETIM 6:EC001439 - Timer relay
- eClass:7.0 27371790
- UNSPSC:39121500
- Object Classification Code:K
角转换，带脉冲延时、脉冲发生器、累积通电延时通／断电延时
2） 通电延时、断电延时，需辅助电源、通电脉冲延时、断电脉冲延时，需辅助电源、对称通／断电延时、通电闪烁，以ON（亮态）开始、通电闪烁，以OFF（暗态）开始、脉冲
发生器、累积通电延时、通／断电延时
3）不对称通／断电延时、通／断电脉冲延时、脉冲发生器，以ON（亮态）开始/以OFF（暗态）开始、单脉冲发生器、通／断电延时
4） 通电延时、断电延时，需辅助电源、通电脉冲延时、断电脉冲延时，需辅助电源、对称通／断电延时、通电闪烁，以ON（亮态）开始、星三角转换，带脉冲延时、脉冲发生
器、累积通电延时、通／断电延时
5）通电闪烁，以ON（亮态）开始、通电闪烁，以OFF（暗态）开始、通电脉冲延时、通电延时、固定脉冲、可调时间延时、可调脉冲、固定时间延时、通／断电延时
6）以上CT型号后缀为“S”的为螺钉连接端子，型号后缀为“P”的为插入式连接端子
